SEMI-AUTOMATIC BLOW MOULDING MAHCINE YD-5000

Product Features
1.Produce bottle from 0.1 L to 2.5L (2 cavity) to 6L (1 cavities).
2.Output capacity up to 1000BPH for 0.11 using two-cavity blow mould.
3.Advanced PLC control system with a use-friendly panel and time-control precision of PLC up to 0.01 second.
4.Equipped with special designed air storage unit.
5.Infrared preform heater.
6.Heating lamps are adjustable in directions to suit various performs.
7.Independent temperature control for different heating lamp to get ideal preform heating results.
Contact Us
  • Specifications

  • General Information

    YD-5000

    Clamping Force

    15T

    Clamping Stroke

    330mm

    Max. Stretching Stroke

    440mm

    Number of Cavities

    0.1-3L 2 Cavity 3-7L 1 Cavity

    Theoretical Output

    0.5-2.5L:350-600BPH 3-6L 1Cavity:300-500BPH

    Max .Mould Thickness

    280mm

    Mould plate size

    490x470mm

    Voltage Standard

    380v/3PH/50Hz or special order

    Total Power(Full Loaded)

    3-10KW 5-15KW

    Min air compressor

    1.2m3/min 3.0Mpa

    Net dimension & Weight (LxWxH)

    Blow Molding Machine

    195x60x180cm

    Pre-heater

    180 x 70 x 140cm

    Net Weight

    1.1T

    Container

    Container Volume

    0.5-7L

    Neck Diameter Range

    28-120mm

    Container Diameter

    300mm

    Container Height

    450mm
