AUTOMATIC BLOW MOULDING MACHINE YD-12000

Product Features
1) High automatization
2) High intelligence: the machine can be controlled through touch screen and running status is shown on it.
3) High quality: steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
4) High speed: 2000BPH(2-cavity), 3000BPH(3-cavity)，4000BPH(4-cavity)，6000BPH(6-cavity)，10000BPH(8-cavity).
5) No contamination: closed production zone, good self-lubrication system avoid contamination.
6) Low cost: low consumption of electricity, air and water.
7) High transparency: easy maintenance, absolute safely, visual inspection, low noise.
Contact Us
  • Specifications

  • General Information

    YD-12000 8 Cavity

    Clamping Force

    100T

    Clamping Stroke

    125mm

    Max. Stretching Stroke

    400mm

    Bottom Moving Stroke

    0-50mm

    Number of Cavities

    10 Cavity

    Theoretical Output

    0.1-1.0L:10000-12000BPH

    Max .Mould Thickness

    300mm

    Mould plate size

    900x670mm

    Total Power(Full Loaded)

    30KW

    Min air compressor

    9.6m3/min 3.0Mpa

    Min air compressor

    2.0m3/min 1.0Mpa

    Electrical System

    Voltage Standard

    380v/3PH/50Hz or special order

    Number of Heating Zone

    6 Sections

    Total Power (Full Loaded）

    78Kw

    Container

    Container Volume

    1.0L

    Neck Diameter Range

    30mm

    Container Diameter

    85mm

    Container Height

    260mm

    Air system

    Low Air compressor

    0.8-1 .0Mpa

    High Air compressor

    3.0-4.0Mpa

    Net dimension & Weight (L x W x H)

    Blow Molding Machine

    855x200x200cm

    Preform Autoloader

    210x120x220cm

    Net Weight

    8.8T
